SPECIFICATION

CPU : LGA1150 Supports Intel® i3/i5/i7 pentium® /celeron® processor supports 1333/1066MHz FSB

Chipset : Intel H81

Memory Support : Supports dual channel DDR3 1333/1066 memory SDRAM (16GB Max.)

Audio : Chip integrated by Realtek® ALC662

LAN : Support Realtek® 10/100Mbps (Gigabit LAN optimal)

Expansion Slots : 1x PCI Express x16 slot

Storage      :    2x SATA 2.0 ports, 2x SATA 3.0 ports

Back Panel I/O Ports : 1x USB 2.0 Keyboard, 1x USB 2.0 Mouse, 1x VGA port, 1x HDMI port, 2x USB 2.0, 2x USB 3.0, 1x RJ-45 port, 3x Audiojack

internal I/O Connector:1x24-pin ATX power connector, 1x4-pin ATX 12V power connector, 1xUSB 3.0 connector support additional 2 USB 3.0 ports, 1x Front panel audio connector, 1x System panel connector

Form Factor : Micro ATX 190X170mm

Form Factor : 1x Driver CD, 1x Manual book, 1x I/O Backboard, 1x SATA Cable
