SPECIFICATION

CPU : LGA1155 Supports Intel i3/i5/i7 series dekstop processor supports 1333/1066MHz FSB

Chipset : Intel H61

Memory Support : Supports dual channel DDR3 1333/1066 memory SDRAM (8GB Max.)

Audio : Chip integrated by Realtek ALC662

LAN : Support Realtek 10/100Mbps (Gigabit LAN optimal)

Expansion Slots : 1x PCI Express x16 slot ,  1x PCI Express x1 slot

Storage      :    4x SATA ports, 1x SATA M.2 NVMe

Back Panel I/O Ports : 1x USB 2.0 Keyboard, 1x USB 2.0 Mouse, 1x VGA port, 1x HDMI port, 2x USB 2.0, 2x USB 3.0, 1x RJ-45 port, 3x Audiojack

internal I/O Connector:1x24-pin ATX power connector, 1x4-pin ATX 12V power connector, 1 x USB 3.0 connector support additional 4 USB ports, 1x LPC_DEBUG connector, 1x Front panel audio connector, 1x System panel connector

Form Factor : Micro ATX 190X170mm

Form Factor : 1x Driver CD, 1x Manual book, 1x I/O Backboard, 1x SATA Cable
